Planer/slotting machine

VERTICAL SLOTTING MACHINE CNC BK5032

  • Type:Vertical slotting machine CNC
  • Model Number: BK5032
  • Origin: Shandong, China
  • Key points of sale:Slotting
  • Trademark: Congou
  • Condition: New
  • Cutting length: 320mm
  • Outgoing Video check: Submitted
  • Size (L*W*H): 2800×2400×2500 mm
  • Weight(kg): 3700
  • Color: Customizable
  • Engine power: 4kw
Get A Quote
Contact Us

VIDEO ABOUT VERTICAL SLOTTING MACHINE CNC BK5032

DESCRIPTION OF VERTICAL SLOTTING MACHINE CNC BK5032

The purpose of the BK5032 rock drill is to use chiseling and irregular straight external surfaces and holes, as well as chiseling various shapes of grooves and grooves in parts manufacturing, instrument manufacturing, machine tool manufacturing, and other industries. On this type of rock drill, metal and non-metallic products, such as plastic products, can be processed.

CHARACRISTICS OF BK5032

ModelBK5032
The maximum length of ram320mm
Ram adjustment stroke315mm
Number of ram movements20-80n/min
Working desk size800×610mm
Table travel350×400mm
The distance between the axis of the tool bearing hole and foream of the column600mm
The distance between the end face of the cutter head support hole and the table540mm
X direction motor torque7.7N.M
Y direction motor torque7.7N.M
Ball screw (X)FFZD3205-3/P4
Ball screw (Y)FFZD3205-3/P4
Main motor power4KW
Machine weight3700kg
Package dimensions2800×2400×2500mm
