VIDEO ABOUT RADIAL DRILLING MACHINE 2A580-1
DISCRIPTION OF RADIAL DRILLING MACHINE 2A580-1
The 2A580-1 radial drilling machine is designed to perform drilling, reaming, countersinking, threading and trimming of ends. In the presence of additional equipment, which can be purchased for a fee, the machine is able to perform milling.
CHARACTRISTICS OF 2A580-1
| Model | 2A580-1 |
| Max.drilling dia. | 80mm |
| Distance between spindle nose and table surface | 350-1585mm |
| Distance from spindle axis to column surface | 500-2070mm |
| Spindle travel | 400mm |
| Spindle taper | MT6 |
| Spindle speed range | 16-1250rpm |
| Spindle speed steps | 16 |
| Spindle feed range | 0.04-3.2mm/r |
| Spindle feed steps | 16 |
| Main motor power | 7.5kw |
| Lifting motor power | 1.5kw |
| Machine weight | 9500kg |
| Overall dimension | 3500×1450×3300mm |
