DESCRIPTION OF CNC LATHE WITH INCLINED BED TCK 40
The machine model TCK40 is a fully functional turning machining center with numerical control, developed and designed using advanced foreign technologies. The design and controls are designed to meet the requirements of ergonomics: it is convenient and easy to operate. This machine is designed to perform turning operations of finishing and semi-finishing, including the processing of cast iron castings, due to the use of a high-speed spindle. Movements along the axes occur along high-precision rolling guides of the HGH35 series, resistant to vibration. They have high rigidity and allow turning with the removal of large allowances. In the presence of appropriate software (CAD /CAM systems) – the key to the efficient operation of CNC machines – the reconfiguration of the machine by a process engineer takes minimal time. You just need to change the program, which reduces the complexity of changeover by 80-90% compared to the complexity of this operation on manually operated machines and ensures the individuality of any complex part. The machines are manufactured according to the GB/T 16462.1-2007 precision standard.
CHARACTERISTICS OF TCK40
| Model | TCK40 |
| Swing over bed | 400mm |
| Swing over cross slide | 140mm |
| Distance between centers | 200mm |
| Spindle bore | 48mm |
| Spindle nose type | A2-5 |
| Spindle speed steps | Stepless |
| Spindle speed range | 3500rpm |
| Turret/tool post | Gang type |
| Tool size | 20 x 20mm |
| X axis travel | 400mm |
| Z axis travel | 300mm |
| X axis rapid traverse | 18000mm/min |
| Z axis rapid traverse | 18000mm/min |
| Main spindle motor | 5.5kw |
| Guide rail type | Linear rail |
| Machine weight | 2300kg |
| Overall dimension | 2200x1600x1780mm |
