VIDEO ABOUT CNC FLAT BED LATHE MACHINE H50
DESCRIPTION OF CNC FLAT BED LATHE MACHINE H50
- Heavy machine bed made of high-quality casting with large, hardened and polished guides
- High torque on the spindle is provided by a 4-speed gearbox with hydraulic shifting and stepless adjustment of powerful drives and ballscrews on all axes
- The CNC is an intuitive and easy-to-learn control system with a large number of cycles for simple programming with the help of an editor – the optimal CNC for serial and single production of parts of complex shape
- A productive cooling system and centralized lubrication are included as standard
CHARACTERISTICS OF H50
| Model | H50 |
| Swing over bed | 500mm |
| Swing over cross slide | 280mm |
| Distance between centers | 1000/1500/2000mm |
| Spindle bore | 52mm |
| Spindle bore taper | MT6 |
| Spindle nose type | C6 |
| Spindle speed range | L：70-560rpm H：200-1600rpm |
| Turret/tool post | Electric 4 position |
| Tool size | 25*25mm |
| X axis travel | 220mm |
| Z axis travel | 1050/1600mm |
| X axis rapid traverse | 6000mm/min |
| Z axis rapid traverse | 8000mm/min |
| Tailstock quill diameter | Ø75mm |
| Tailstock quill taper | MT5 |
| Tailstock quill travel | 140mm |
| Main spindle motor | 7.5kw |
| Machine weight | 2000/2500kg |
| Overall dimension | 2500/3000*1500*1650mm |
