VIDEO ABOUT CNC FLAT BED LATHE MACHINE H30
DESCRIPTION OF CNC FLAT BED LATHE MACHINE H30
- Heavy machine bed made of high-quality casting with large, hardened and polished guides
- High torque on the spindle is provided by a 4-speed gearbox with hydraulic shifting and stepless adjustment of powerful drives and ballscrews on all axes
- The CNC is an intuitive and easy-to-learn control system with a large number of cycles for simple programming with the help of an editor – the optimal CNC for serial and single production of parts of complex shape
- A productive cooling system and centralized lubrication are included as standard
CHARACTERISTICS OF H30
| Model | H30 |
| Swing over bed | 300mm |
| Swing over cross slide | 100mm |
| Distance between centers | 500/700mm |
| Spindle bore | 60mm |
| Spindle bore taper | MT6 |
| Spindle nose type | A2-5 |
| Spindle speed steps | Stepless |
| Spindle speed range | 100-2000rpm |
| Turret/tool post | Electric 4 position |
| Tool size | 20*20mm |
| X axis travel | 160mm |
| Z axis travel | 500mm |
| X axis rapid traverse | 6000mm/min |
| Z axis rapid traverse | 8000mm/min |
| Tailstock quill diameter | Ø50mm |
| Tailstock quill taper | MT4 |
| Tailstock quill travel | 90mm |
| Main spindle motor | 4kw |
| Coolant pump motor | 0.09kw |
| Machine weight | 800kg |
| Overall dimension | 1500*1000*1600mm |
