DESCRIPTION OF SHAPER MACHINE BC60125
Shaper BC60120 is mainly used for planning the plane on the small and medium-sized workpieces in small bench production of a single piece, forming the surface and grooves. Planer bench can turning angel of the table with horizontal and lift moving mechanism; for planning the inclined plane, thereby expanding the scope of use.
CHARACTERISTICS OF BC60125
| Model | BC60125 |
| cutting length | 1250mm |
| Max.distance from the undersurface of ram to the worktable | 400mm |
| Max.working distance of knife rest | 160mm |
| Max.cutting force | 28kN |
| Ram stroke reciprocating table for each level of the scope of the direction of feed | 0.25～5mm |
| Working speed of the ram | 3-38m/min |
| Table area（length*width） | 1250×500mm |
| The width of the T—solt in the center of the worktable | 22mm |
| Max.lateral process of the worktable | 1200mm |
| Main motor power | 7.5kw |
| Overall Dimensions（L*W*H） | 4140×1950×1850mm |
| The weight of the machine | 4700kg |
